PORT INFORMATION

• Terminal Name: Sociedad Portuaria del Golfo de Morrosquillo
• Port: Santiago de Tolu
• VHF: 16
• Prevailing weather conditions: Windy and soft swelling
• Length of wharf: 260 mts
• Type of wharf: Pilotted platform
• Max LOA: 200 mts
• Max Beam: 32.2 mts
• Max Draft allowed alongside: 9.75 Mts / 32.00 ft
• Under keel clearance: 0.24 Mts / 0.8 ft
• Total depth alongside: 9.99 Mts / 32.80 ft
• Water density (currently): 1.020 BW
• Tidal restriction berth / unberth: No
• Max air draft allowed: 11.5 mts
• Berthing / Unberthing time: Night restrictions at windy season
• Working time: 24 hrs SHINC
• Superholidays: According with C/P
• Berthing side: Either Port or Starboardside
• Tug boats: Compulsory
• Loading system for bulk cargoes: Conveyor belt
• Distance traveled by shore shiploader: Fixed
• Cargo quantity determined by: Draft survey

Loading rates:

• Cement in bulk: SF 28 cu-ft x MT / 10.120 MT x day
• Clinker: SF 32 cu-ft x MT / 9.000 MT x day
• Coal: SF 42-46 cu-ft x MT / 9.000 MT x day
• Pre-slung cement: SF 32 cu-ft x MT / 2.000 MT x day
• Discharging rate (take away capacity): 5.000 MT x day
• Distance between fender and hoppers centerline: 3.5 mts
• Hoppers Traveling distance: Manual adjustment mounted over skies
• Hoppers quantity and capacity: 3 x 15 cu-MT each
• No bunker supply allowed alongside
• Supplies & disposals are available through agents
• Maintenance works onboard not allowed without port authorities authorization.
• Antinarcotics police inspection is compulsory
• Divers hull inspection on vessel charge is compulsory
• Private guards on board on vessel charge is compulsory
• TOLU Pilot Station position: Latitude: 9? 29.6' North / Length: 75? 35.6' West Located 1.3 to 1.5 NM outside harbor
